INFINITE VRLA AGM Battery — 12IP12VA [12V 12Ah]

INFINITE VRLA AGM Battery — 12IP12VA [12V 12Ah]

0 review

Rated 5 out of 5

Designed floating charging service life: 8 years (25ºC)
Sealed and maintenance free operation
Safety valve installation for explosion proof
Low self-discharge characteristic
Wide operating temperature range from 0ºC~40ºC
Lead Aluminum calcium Tin alloy high energy, prevent corrosion

Designed floating charging service life: 8 years (25ºC)
Sealed and maintenance free operation
Safety valve installation for explosion proof
Low self-discharge characteristic
Wide operating temperature range from 0ºC~40ºC
Lead Aluminum calcium Tin alloy high energy, prevent corrosion

Chat on WhatsApp

Categories INFINITE, VRLA AGM Battery

Nominal Voltage	12V
Nominal Capacity (20HR)	12AH
Length (L)	151±2mm
Width (W)	98±2mm
Height (H)	95±2mm
Total Height (TH)	100±2mm
Weight ±3%	Approx 3.12kg
Internal Resistance	≈23.1 mΩ
Standard Terminals	F01/F02 (standard)

Rated Capacity
20 hour rate (0.60A)	12.0AH
10 hour rate (1.20A)	11.3AH
5 hour rate (2.04A)	10.2AH
27 minute rate (12.0A)	5.4AH
7 minute rate (36.0A)	4.2AH

Capacity affected by Temperature
40ºC (104ºF)	103%
25ºC (77ºF)	100%
0ºC (32ºF)	86%

Cycle Application

Limit initial current less than 3.6A.
Charge until battery voltage (under charge) reaches 14.1V to 14.4V at 25ºC (77ºF).
Hold at 14.1V to 14.4V until current drop to under 0.072A for at least 3 hours.
Temperature compensation coefficient of charging voltage is -30mV/ºC.

Standby Service

Hold battery across constant voltage source of 13.6 to 13.8 volts with current limit 3.6A continuously. When held at this voltage, the battery will seek its own current level and maintain itself in a fully charge status.
Temperature compensation coefficient of charging voltage is -18mV/ºC.

End Voltage (V)	Minute (M)				Hour (H)
End Voltage (V)	10	15	30	45	1	1.5	2	3	5	8	10	20
Constant Current Discharge Data Sheet (@25ºC) Unit: A
9.6V	31.9	25.0	12.8	8.98	7.56	6.02	4.48	3.38	2.38	1.81	1.17	0.624
9.9V	30.4	23.8	12.1	8.66	7.38	5.88	4.37	3.30	2.32	1.78	1.16	0.618
10.2V	28.9	22.7	11.6	8.38	7.20	5.74	4.26	3.22	2.26	1.74	1.15	0.612
10.5V	28.7	22.4	11.5	8.29	7.15	5.63	4.10	3.12	2.04	1.55	1.14	0.606
10.8V	28.3	22.2	11.3	8.21	7.10	5.52	3.94	3.00	1.98	1.36	1.13	0.600

End Voltage (V)	Minute (M)				Hour (H)
End Voltage (V)	10	15	30	45	1	1.5	2	3	5	8	10	20
Constant Power Discharge Data Sheet (@25ºC) Unit: W
9.6V	385	311	176	125	93	71	53.6	38.3	25.2	17.6	13.9	7.51
9.9V	367	296	168	120	91	69	52.3	37.3	24.6	17.3	13.8	7.44
10.2V	349	282	160	116	88	68	51.0	36.4	24.0	16.9	13.7	7.37
10.5V	337	274	156	114	87	67	50.3	35.6	23.8	16.8	13.4	7.26
10.8V	325	265	151	111	86	66	49.6	34.9	23.4	16.6	13.2	7.16

Description
Reviews (0)

Description

Designed floating charging service life: 8 years (25ºC)
Sealed and maintenance free operation
Safety valve installation for explosion proof
Low self-discharge characteristic
Wide operating temperature range from 0ºC~40ºC
Lead Aluminum calcium Tin alloy high energy, prevent corrosion
