INFINITE VRLA AGM Battery — 12IP35VA [12V 35Ah]

INFINITE VRLA AGM Battery — 12IP35VA [12V 35Ah]

0 review

Rated 5 out of 5

Designed floating charging service life: 8 years (25ºC)
Sealed and maintenance free operation
Safety valve installation for explosion proof
Low self-discharge characteristic
Wide operating temperature range from 0ºC~40ºC
Lead Aluminum calcium Tin alloy high energy, prevent corrosion

Designed floating charging service life: 8 years (25ºC)
Sealed and maintenance free operation
Safety valve installation for explosion proof
Low self-discharge characteristic
Wide operating temperature range from 0ºC~40ºC
Lead Aluminum calcium Tin alloy high energy, prevent corrosion

Chat on WhatsApp

Categories INFINITE, VRLA AGM Battery

Nominal Voltage	12V
Nominal Capacity (10HR)	35AH
Length (L)	196±2mm
Width (W)	130±2mm
Height (H)	158±2mm
Total Height (TH)	162±2mm
Weight ±3%	Approx 9.5kg
Internal Resistance	≈8.6 mΩ
Standard Terminals	T06 (standard)

Rated Capacity
20 hour rate (1.65A)	36.60AH
10 hour rate (3.30A)	35.00AH
5 hour rate (5.61A)	29.75AH
27 minute rate (33A)	15.75AH
7 minute rate (99A)	12.25AH

Capacity affected by Temperature
40ºC (104ºF)	103%
25ºC (77ºF)	100%
0ºC (32ºF)	86%

Cycle Application

Limit initial current less than 10.5A.
Charge until battery voltage (under charge) reaches 14.1V to 14.4V at 25ºC (77ºF).
Hold at 14.1V to 14.4V until current drop to under 0.198A for at least 3 hours.
Temperature compensation coefficient of charging voltage is -30mV/ºC.

Standby Service

Hold battery across constant voltage source of 13.6 to 13.8 volts with current limit 10.5A continuously. When held at this voltage, the battery will seek its own current level and maintain itself in a fully charge status.
Temperature compensation coefficient of charging voltage is -18mV/ºC.

End Voltage (V)	Minute (M)				Hour (H)
End Voltage (V)	10	15	30	45	1	1.5	2	3	5	8	10	20
Constant Current Discharge Data Sheet (@25ºC) Unit: A
9.6V	88.2	69.1	35.3	24.9	20.9	16.5	12.2	9.26	5.98	3.96	3.42	1.77
9.9V	84.0	65.8	33.6	24.0	20.4	16.1	11.9	9.03	5.83	3.89	3.38	1.76
10.2V	80.0	62.7	32.0	23.2	19.9	15.8	11.6	8.81	5.69	3.81	3.35	1.74
10.5V	79.2	62.0	31.7	23.1	19.8	15.5	11.2	8.54	5.61	3.77	3.32	1.72
10.8V	78.3	61.4	31.5	23.0	19.7	15.3	10.8	8.26	5.47	3.73	3.30	1.69

End Voltage (V)	Minute (M)				Hour (H)
End Voltage (V)	10	15	30	45	1	1.5	2	3	5	8	10	20
Constant Power Discharge Data Sheet (@25ºC) Unit: W
9.6V	992	803	454	321	239	184	138	99	65	45.4	36.0	19.4
9.9V	945	765	432	310	234	179	135	96	63	44.5	35.6	19.2
10.2V	900	728	412	300	228	175	132	94	62	43.6	35.3	19.0
10.5V	870	707	403	293	224	172	130	92	61	43.2	34.8	18.7
10.8V	838	684	391	285	220	170	128	90	60	42.8	34.2	18.5

Description
Reviews (0)

Description

Designed floating charging service life: 8 years (25ºC)
Sealed and maintenance free operation
Safety valve installation for explosion proof
Low self-discharge characteristic
Wide operating temperature range from 0ºC~40ºC
Lead Aluminum calcium Tin alloy high energy, prevent corrosion
